9dBi UHF RFID Personnel Tracking Ground Mat Antenna
9dBi UHF RFID Personnel Tracking Ground Mat Antenna
Model: APRIA8009CE
Frequency Range: 865-868MHz
Polarization: Circular
Gain: 9dBi
Prodcut Descriptions
The APRIA8009CE 9dBi Circular Panel Antenna is a UHF RFID Ground Mat Antenna designed for reliable UHF RFID applications in the 865-868MHz range. With 9dBi gain, circular polarization, and a 80° × 40° beamwidth, it provides stable tag detection and coverage. Its IP65-rated ABS radome makes it suitable for Applications, RFID Logistics tracking, Warehouse applications, Access control system, Marathon track management or semi-outdoor RFID applications.
Descriptions & Applications
Descriptions
- 865-868MHz
- 9dBi
- Circular Polarization
- 1200*500*41mm
Applications
- RFID Logistics tracking
- Warehouse applications
- Access control system
- Marathon track management
Product Specifications
Electrical Specifications | |
Frequency | 865-868MHz |
Gain | 9dBi |
Beam width | Hor：80° Ver：40° |
Polarization | Circular |
VSWR | ≤1.5 |
F/B Ratio | ≥20 |
Impedance | 50Ω |
Maximum power | 100W |
Lightning protection | DC Ground |
Connector | SMA-Female |
Mechanical Specifications | |
Antenna dimensions | 1200*500*41mm |
Net weight | 3.8kg |
Packing size | 122*52*6cm |
Gross weight | 4kg |
Radome material | Aluminum |
Radome colour | Black |
Operating temperature | -40-70℃ |
IP Rating | IP65 |
Antenna Pattern
H-Plane
E-Plane
Antenna Drawing
Applications
Warehouse Management
Optimizes inventory handling in distribution centers and warehouses by automating item identification and movement, improving operational efficiency.
RFID logistics tracking
Enhances logistics operations by enabling real-time item identification and tracking throughout transportation, sorting, and distribution processes, improving visibility and efficiency.
Access control system
Enhances access management by automatically identifying authorized RFID tags at entry and exit points, enabling fast and reliable access control.
Marathon track management
